Moven
Fireplace stoves
Fireplace stoves
Moven
Description of the product:
It is a steel NORDflam fireplace stove, featuring primary and secondary air adjustment and the furnace is lined with fireclay bricks. The stove also features the deflector, a grill and an ash tray.
Main parameters:
112 kg
Weight
5 kW
Rated output
150 mm
Exhaust outlet diameter
79 %
Heating efficiency
0,11 %
CO emission at 13% O2
325 °C
Exhaust gas temperature °C
50 m2
Heating area (m2)
963x505x345 mm
Dimensions
wood of deciduous trees
Fuel type
cast-iron
Material
A
Energy efficiency class
100 mm
External air supply standard – air inlet diameter
Parameters ECODESIGN
69 %
Seasonal energy efficiency at 13% O2
113
Organic gaseous carbon (OGC) emission at 13% O2
36
Particle matter (PM) emission at 13% O2
46
Nitrogen oxide (NOx) emission at 13% O2
1310
Carbon Oxide (CO) emission at 13% O2
Additional characteristic:
External air supply inlet (CDP) – External air supply
Using external air supply system (CDP) enables the insert independently from the indoor air inside the building. The CDP system can adjust the effectiveness of the insert and lower the hazardous gases emission into the environment. The insert with the CDP system can be used in buildings with mechanical ventilation. The air flows into the furnace via the air inlet (100 mm diameter) placed at the back of the base of the insert. The air inlet can be installed under or at the back of the base.
Using external air supply system (CDP) enables the insert independently from the indoor air inside the building. The CDP system can adjust the effectiveness of the insert and lower the hazardous gases emission into the environment. The insert with the CDP system can be used in buildings with mechanical ventilation. The air flows into the furnace via the air inlet (100 mm diameter) placed at the back of the base of the insert. The air inlet can be installed under or at the back of the base.
Deflector - extends the way fumes travel inside the device, increases heat emissions and heat efficiency of the product.
Afterburning - reduces hazardous gases emission into the environment
Double side and back walls of the furnace - protect the body of the insert and increases its parameters..
Grill
prevents the logs from falling out of the insert
limits the sooth build up on the inside part of the glass
withholds the temperature up to 700 °C
