Etna
Products Fireplace inserts Etna

Etna

Fireplace inserts

Fireplace inserts

Etna

Main parameters:
expand roll
81 kg Weight
13 kW Rated output
180 mm Exhaust outlet diameter
68 % Heating efficiency
0,10 % CO emission at 13% O2
<550 °C Exhaust gas temperature °C
130 m2 Heating area (m2)
622x655x410 mm Dimensions (height, depth, width)
wood of deciduous trees Fuel type
steel, cast-iron Material
A Energy efficiency class
2 years Warranty
100 mm External air supply standard – air inlet diameter
Parameters ECODESIGN
expand roll
60 % Seasonal energy efficiency at 13% O2
<120 Organic gaseous carbon (OGC) emission at 13% O2
<50 Particle matter (PM) emission at 13% O2
<200 Nitrogen oxide (NOx) emission at 13% O2
<2000 Carbon Oxide (CO) emission at 13% O2
Additional characteristic:
expand roll
Deflector - extends the way fumes travel inside the device, increases heat emissions and heat efficiency of the product.
Grill
Side glass panel - increases vision of fire.
Air vent adjusts the chimney draught.
prevents the logs from falling out of the insert
withholds the temperature up to 700 °C

Download:

energy efficiency class mechanical drawing ecodesign declaration
