Torn lux
Products Fireplace inserts Torn lux

Torn lux

Fireplace inserts

Torn lux

Description of the product:
expand roll

Due to black decor frame, TORN Lux fireplace insert is an ideal product that fits modern interiors and offers functionality and stylish design.

Main parameters:
expand roll
126 kg Weight
14 kW Rated output
180 mm Exhaust outlet diameter
71 % Heating efficiency
0,12 % CO emission at 13% O2
330 °C Exhaust gas temperature °C
140 m2 Heating area (m2)
713x690x435 mm Dimensions
wood of deciduous trees Fuel type
cast-iron Material
A Energy efficiency class
100 mm External air supply standard – air inlet diameter
Parameters ECODESIGN
expand roll
61 % Seasonal energy efficiency at 13% O2
118 Organic gaseous carbon (OGC) emission at 13% O2
40 Particle matter (PM) emission at 13% O2
130 Nitrogen oxide (NOx) emission at 13% O2
1500 Carbon Oxide (CO) emission at 13% O2
Additional characteristic:
expand roll
External air supply inlet (CDP) – External air supply
Using external air supply system (CDP) enables the insert independently from the indoor air inside the building. The CDP system can adjust the effectiveness of the insert and lower the hazardous gases emission into the environment. The insert with the CDP system can be used in buildings with mechanical ventilation. The air flows into the furnace via the air inlet (100 mm diameter) placed at the back of the base of the insert. The air inlet can be installed under or at the back of the base.
Deflector - extends the way fumes travel inside the device, increases heat emissions and heat efficiency of the product.
Grill
Decor glass - glass with black, decorative frame.
Air vent adjusts the chimney draught.
prevents the logs from falling out of the insert
withholds the temperature up to 700 °C

Download:

energy efficiency class mechanical drawing ecodesign declaration
