Trent
Fireplace inserts
Fireplace inserts
Trent
Main parameters:
114 kg
Weight
12 kW
Rated output
180 mm
Exhaust outlet diameter
67 %
Heating efficiency
0,13 %
CO emission at 13% O2
<550 °C
Exhaust gas temperature °C
120 m2
Heating area (m2)
693x658x450 mm
Dimensions (height, depth, width)
wood of deciduous trees
Fuel type
steel, cast-iron
Material
A
Energy efficiency class
5 years
Warranty
100 mm
External air supply standard – air inlet diameter
Parameters ECODESIGN
57 %
Seasonal energy efficiency at 13% O2
118
Organic gaseous carbon (OGC) emission at 13% O2
41
Particle matter (PM) emission at 13% O2
130
Nitrogen oxide (NOx) emission at 13% O2
1625
Carbon Oxide (CO) emission at 13% O2
Additional characteristic:
External air supply inlet (CDP) – External air supply
Using external air supply system (CDP) enables the insert independently from the indoor air inside the building. The CDP system can adjust the effectiveness of the insert and lower the hazardous gases emission into the environment. The insert with the CDP system can be used in buildings with mechanical ventilation. The air flows into the furnace via the air inlet placed at the back of the base of the insert. The air inlet can be installed under or at the back of the base.
Using external air supply system (CDP) enables the insert independently from the indoor air inside the building. The CDP system can adjust the effectiveness of the insert and lower the hazardous gases emission into the environment. The insert with the CDP system can be used in buildings with mechanical ventilation. The air flows into the furnace via the air inlet placed at the back of the base of the insert. The air inlet can be installed under or at the back of the base.
Deflector - extends the way fumes travel inside the device, increases heat emissions and heat efficiency of the product.
Grill
Side glass panel - increases vision of fire.
Air vent adjusts the chimney draught.
prevents the logs from falling out of the insert
withholds the temperature up to 700 °C
