Trent
Products Fireplace inserts Trent

Trent

Fireplace inserts

Fireplace inserts

Trent

Main parameters:
expand roll
114 kg Weight
12 kW Rated output
180 mm Exhaust outlet diameter
67 % Heating efficiency
0,13 % CO emission at 13% O2
<550 °C Exhaust gas temperature °C
120 m2 Heating area (m2)
693x658x450 mm Dimensions (height, depth, width)
wood of deciduous trees Fuel type
steel, cast-iron Material
A Energy efficiency class
100 mm External air supply standard – air inlet diameter
Parameters ECODESIGN
expand roll
57 % Seasonal energy efficiency at 13% O2
118 Organic gaseous carbon (OGC) emission at 13% O2
41 Particle matter (PM) emission at 13% O2
130 Nitrogen oxide (NOx) emission at 13% O2
1625 Carbon Oxide (CO) emission at 13% O2
Additional characteristic:
expand roll
Deflector - extends the way fumes travel inside the device, increases heat emissions and heat efficiency of the product.
Grill
Side glass panel - increases vision of fire.
Air vent adjusts the chimney draught.
prevents the logs from falling out of the insert
withholds the temperature up to 700 °C

Download:

energy efficiency class mechanical drawing ecodesign declaration
