Toria
Products Fireplace stoves Toria

Toria

Fireplace stoves

Toria

Description of the product:
expand roll

It is the largest fireplace stove completing the NORDflam fireplace stove range. The stove features adjustable, tertiary air supply system, where the air flows into the furnace from the orifices located at the back plate. The effect called afterburning further burns the wood gases that are released in the burning process. Additionally the stove is equipped in a cast-iron side doors allowing for loading longer wood logs without the necessity of opening the front doors.


Main parameters:
expand roll
175 kg Weight
11 kW Rated output
150 mm Exhaust outlet diameter
71 % Heating efficiency
0,15 % CO emission at 13% O2
356 °C Exhaust gas temperature °C
110 m2 Heating area (m2)
865x773x493 mm Dimensions
wood of deciduous trees Fuel type
cast-iron Material
A Energy efficiency class
Parameters ECODESIGN
expand roll
61 % Seasonal energy efficiency at 13% O2
118 Organic gaseous carbon (OGC) emission at 13% O2
49 Particle matter (PM) emission at 13% O2
130 Nitrogen oxide (NOx) emission at 13% O2
1834 Carbon Oxide (CO) emission at 13% O2
Additional characteristic:
expand roll
Deflector - extends the way fumes travel inside the device, increases heat emissions and heat efficiency of the product.
Afterburning - reduces hazardous gases emission into the environment
Double side and back walls of the furnace - protect the body of the insert and increases its parameters..
Grill
prevents the logs from falling out of the insert
limits the sooth build up on the inside part of the glass
withholds the temperature up to 700 °C

Download:

energy efficiency class mechanical drawing ecodesign declaration
