Products Fireplace stoves Sora

Sora

Fireplace stoves

Fireplace stoves

Sora

Main parameters:
expand roll
89 kg Weight
7 kW Rated output
130 mm Exhaust outlet diameter
81 % Heating efficiency
330 °C Exhaust gas temperature °C
70 m2 Heating area (m2)
879x383x394 mm Dimensions (height, depth, width)
wood of deciduous trees Fuel type
cast-iron Material
A+ Energy efficiency class
2 years Warranty
85.9 mm External air supply standard – air inlet diameter
Parameters ECODESIGN
expand roll
71 % Seasonal energy efficiency at 13% O2
86 Organic gaseous carbon (OGC) emission at 13% O2
30 Particle matter (PM) emission at 13% O2
62 Nitrogen oxide (NOx) emission at 13% O2
1089 Carbon Oxide (CO) emission at 13% O2
Additional characteristic:
expand roll
External air supply inlet (CDP) – External air supply
Using external air supply system (CDP) enables the insert independently from the indoor air inside the building. The CDP system can adjust the effectiveness of the insert and lower the hazardous gases emission into the environment. The insert with the CDP system can be used in buildings with mechanical ventilation. The air flows into the furnace via the air inlet placed at the back of the base of the insert. The air inlet can be installed under or at the back of the base.
Deflector - extends the way fumes travel inside the device, increases heat emissions and heat efficiency of the product.
Double deflector
Afterburning - reduces hazardous gases emission into the environment
Grill
limits the sooth build up on the inside part of the glass
withholds the temperature up to 700 °C
Recuperation - Adapted for homes with recuperation systems

Download:

declaration of performance and conformity energy efficiency class manual mechanical drawing product sheet rating plate technical data
